Electric Standing Wheelchair – Dual 250W Motors, 32Ah Battery & 28km+ Range

Electric Standing Wheelchair – Dual 250W Motors, 32Ah Battery & Powered Standing

The JRWD1003U Electric Standing Wheelchair combines everyday powered mobility with supported electric standing, adjustable positioning, electric/manual drive modes, and intelligent electromagnetic braking.

Powered by dual 250W motors and a 24V 32Ah battery, the wheelchair offers a manufacturer-listed driving range of 28 km or more, a maximum speed of 6 km/h (3.7 mph), and a 100 kg / 220 lb maximum load capacity.

Its high-back seat, adjustable headrest, flip-up armrests, leg-positioning panels, foot platform, programmable joystick controller, and automatic braking system provide a comprehensive mobility and positioning solution for appropriate users.

Key Features

🧍 Electric Standing Function

The wheelchair features a powered standing system designed to transition an appropriate user from seated mobility toward a supported upright position.

The seat, backrest, leg-positioning panels, and foot platform work together to maintain body positioning during the transition.

⚡ Dual 250W Motor System

The JRWD1003U is equipped with:

250W × 2 motors

for approximately 500W combined rated motor power.

The supplier describes the upgraded motor system as providing strong output with lower operating noise and reduced energy consumption.

🔋 24V 32Ah High-Capacity Battery

The wheelchair uses a:

24V 32Ah battery

providing a manufacturer-listed maximum driving range of:

≥28 km / approximately 17.4 miles

The manufacturer lists an approximate 8-hour charging time.

Actual range can vary according to user weight, terrain, speed, incline, battery condition, temperature, tire pressure, and other operating conditions.

🚀 Maximum Speed of 6 km/h

Maximum manufacturer-listed speed:

6 km/h / approximately 3.7 mph

This provides controlled powered mobility for appropriate everyday environments.

🎮 360° Joystick Controller

The intelligent joystick provides 360° directional control for intuitive maneuvering.

The controller incorporates:

Power On/Off
Battery-Level Display
Horn
Speed Indicator
Acceleration
Deceleration
Directional Joystick

✋ One-Hand Operation

The joystick system is designed for single-hand control, allowing the wheelchair's primary driving functions to be operated from one controller.

5️⃣ Five-Speed Adjustment

The controller provides five speed levels, allowing the user to select an appropriate operating speed for different environments.

It also provides a five-level battery indicator for convenient battery monitoring.

↔️ Left- or Right-Hand Controller Installation

The controller can be installed on either the left or right side of the wheelchair.

This provides additional flexibility according to the user's preferred control hand.

🛑 Intelligent Electromagnetic Brake

The wheelchair incorporates a fully automatic electromagnetic braking system.

According to the manufacturer, releasing the controller brings the wheelchair to a stop, helping reduce unintended rolling on appropriate slopes.

⚙️ Electric / Manual Dual Mode

The wheelchair supports both:

Electric Mode – Powered mobility using the motor system.

Manual Mode – Allows the wheelchair to be moved manually when appropriate.

The drive mechanism uses a 90° switching system to change between electric and manual operation.

💺 High-Back Supportive Seat

A tall, supportive backrest provides upper-body support during seated mobility and appropriate standing operation.

The upholstery is described as breathable and designed for easier cleaning.

🧠 Adjustable Headrest

The integrated headrest provides additional head and upper-body support.

🤲 Flip-Up Armrests

The armrests can be lifted/flipped away, providing additional side clearance for appropriate transfers between the wheelchair and a bed, chair, or other surface.

🦵 Leg-Positioning Panels

Dedicated leg panels help support and stabilize the user's lower body during supported standing.

🦶 Supportive Foot Platform

The integrated foot platform provides a stable surface for the user's feet during seated and supported upright positioning.

🛞 12-Inch Main Wheels + 8-Inch Caster Wheels

The manufacturer's diagram identifies:

Main Wheels: 12 inches
Caster Wheels: 8 inches

These wheels provide the wheelchair's primary mobility and maneuverability platform.

🏠 Indoor & Outdoor Mobility

The supplier shows the wheelchair being used in several environments, including:

Indoor/home environments
Parks and outdoor paved areas
Appropriate slopes
General everyday mobility

Surface conditions, slope limits, and manufacturer operating instructions should always be considered before use.

Comfort & Safety Details

The JRWD1003U includes several additional design features intended to improve everyday usability, including flip-up armrests, a safety positioning belt, anti-tip/rear support components, reversing audible alerts, breathable upholstery, electromagnetic braking, and adjustable positioning components.

Complete Specifications

Specification	Details
Model	JRWD1003U
Product Type	Electric Standing Wheelchair
Motor	DC 250W × 2
Combined Rated Motor Power	Approx. 500W
Battery	24V 32Ah
Maximum Range	≥28 km / Approx. 17.4 miles
Maximum Speed	6 km/h / Approx. 3.7 mph
Charging Time	Approx. 8 Hours
Maximum Load Capacity	100 kg / Approx. 220 lbs
Wheelchair Weight	114.5 kg / Approx. 252 lbs
Overall Dimensions	1110 × 630 × 1280 mm
Seat Width	450 mm / 17.7"
Seat Depth	500 mm / 19.7"
Front Seat Height from Ground	510 mm / 20.1"
Armrest Height	290 mm / 11.4"
Backrest Height	650 mm / 25.6"
Main Wheel Diameter	12"
Caster Wheel Diameter	8"
Turning Radius	1.2 m
Dynamic Stability	6°
Static Stability	9°
Braking Distance / Performance	Manufacturer lists 1.5 m
Backrest Adjustable Angle	≥30°
Legrest Adjustable Angle	≥60°
Tire Pressure	2 kgf/cm²
Controller Max. Output Current	35A
Controller	360° Joystick
Speed Levels	5
Battery Indicator Levels	5
Controller Position	Left or Right Side
Drive Modes	Electric + Manual
Brake System	Automatic Electromagnetic Brake
Standing Function	Powered / Electric

Designed for Greater Positioning Flexibility

The JRWD1003U is more than a conventional power wheelchair. Its combination of powered mobility, supported standing, dual 250W motors, 32Ah battery, electric/manual operation, 360° joystick control, electromagnetic braking, adjustable leg and back support, and accessible transfer features creates a versatile mobility platform for appropriate users.

With a manufacturer-listed 28+ km range, five selectable speed levels, one-hand joystick operation, and the ability to mount the controller on either side, the wheelchair is designed to provide greater flexibility for everyday mobility.
